Production Capacity:100000PCS/Year
Transport Package:Carton Packaging and Packaging According to Custom
Payment Terms:L/C, T/T
Designed for use in high-stress environments, our steel circular shafts are ideal for various machinery components such as driveshafts, axles, and rotors. The precision machining of these shafts guarantees tight tolerances, smooth finishes, and excellent balance, which are essential for maintaining the reliability and efficiency of aerospace and automotive systems.
CNC Machining Parts parameter
Summary of the company's products | |
Manufacture | Qingdao GuangMei Precision Machinery co.,Ltd |
Main processing products | precision fixture processing, precision machinery axle processing,spare parts,machined part. |
Material | Q235,S25C,S45C,S50C,S55C,SUS440C,SCM415, SUS304,SUS316,SUS303,A5052,A6061,A7075, SUJ2,SKD11,SKS3 |
Surface Roughness | Ra0.4mm~ |
Concentricity | ±0.005mm |
Straightness | ± 0.02mm |
Precision | ±0.003mm |
Surface Treatment | TiCN,TiN,Aitain,Ticrn,Dlc,Ni coating,Black coating ,Cr couting,etc |
Hardness | HRC20-60 |
Standard | JIS,DIN,ASTM/AISI international industrial standard |
MOQ | 1 Piece |
Supply Capability | 10000 pieces/Month |
Delivery way | EMS,OCS,DHL,UPS,FEDEX,Shipping |
CNC Machining Parts details
Production and processing accuracy range:
CNC lathe turning: outer diameter Φ 2-590mm, tolerance ± 0.005mm
Machining center: 900x600mm (length x width), tolerance ± 0.02mm
Grinding: Precision can reach a tolerance of about ± 0.001mm
External cylindrical grinding machine processing: accuracy can reach a tolerance of ± 0.002~0.005m
CNC Machining Parts Related products
Production and processing accuracy range:
CNC lathe turning: outer diameter Φ 2-590mm, tolerance ± 0.005mm
Machining center: 900x600mm (length x width), tolerance ± 0.02mm
Grinding: Precision can reach a tolerance of about ± 0.001mm
External cylindrical grinding machine processing: accuracy can reach a tolerance of ± 0.002~0.005mm
Main Equipment
Main Equipment | |||||
NO | Equipment Name | BRAND TYPE | QT,Y | UNIT | NOTE |
1 | WIRE CUTTING | MITSUBISI FA10S | 1 | SET | |
2 | SUPPER DRILL | SUPPER DRILL | 1 | SET | |
3 | EDM | CREATION | 2 | SET | |
4 | EDM | SODICK AQ36L | 1 | SET | |
5 | EDM | SODICK AD30L | 2 | SET | |
6 | MACHINE CENTER | DOOSAN | 1 | SET | |
7 | MACHINE CENTER | JIATIE | 1 | SET | |
8 | Precision large water mill | PROTH | 1 | SET | |
9 | LATHE | CDE6140A | 2 | SET | |
10 | NC LATHE | 5 | SET | ||
11 | Outer round grinding | 1 | SET | ||
12 | Heartless Grinding | 1 | SET | ||
13 | GRINDE | CGM-200BS | 1 | SET | |
14 | GRINDE | CGM-618VS | 1 | SET | |
15 | GRINDE | ZHUNLI 618M | 5 | SET | |
16 | GRINDE | 618M | 6 | SET | |
17 | LASER MARKING | 1 | SET | ||
18 | END MILLING | TOPONE | 2 | SET | |
19 | Wanhao Projector AND MITSUTOYO | 200 mm | 3 | SET | |
20 | Marble Level Platform | 450× 450 *100mm | 14 | EA | |
21 | Tool Microscope | 0.001MM | 3 | SET | |
22 | MITSUTOYO Digital micrometer | 0 ~ 25mm,25 ~ 50mm | 5 | EA | |
23 | MITSUTOYO Digital micrometer | 150mm, 200mm, 300mm | 6 | EA | |
24 | MITSUTOYODial indicator | 1/1000 mm | 10 | EA | |
25 | MITSUTOYO HEIGHT GAGE ,NIKON | 300 mm | 10 | EA | |
26 | BLOCK GAGE | 1.005mm~100mm | 15 | SET | |
27 | Lever micrometer | 1/100 mm | 5 | EA | |
28 | Inner diameter percentage meter | 1/100 mm | 3 | EA | |
29 | MITSUTOYO External diameter micrometer | 0 ~ 25 mm | 5 | EA |
